OBO Bettermann 2024217 Cable gland 1.5 mm Plastic, PA 1 pc(s)
Product type
Cable gland
External thread
PG16
Type
straight
Material
Plastic
PA
Clamp Ø
7 mm
EAN:
Part number:
Item no:
Technical specifications
- Thread type: PG
- Thread size metric/PG: 16
- Suitable for cable diameter 7..14 mm
- Surface: Untreated
- Glass-fiber reinforced: No.
- Shock-resistant: No.
- Colour: Other
- Bend protection: No.
- With locknut: No.
- Multiple sealing application: No.
- Flat cable screwing: No.
- With strain relief: Yes
- Type of seal: Sealing ring
- Separable screw connection: No
- Explosion-tested version: No.
- For Ex-zone gas: Without
- For Ex-Zone Dust: Without
- Product type
Cable gland
- Features
with strain relief
- External thread
PG16
- Internal thread
1.5 mm
- Type
straight
- Material
Plastic
PA
- Clamp Ø
7 mm
- Terminal Ø (max.)
14 mm
- Thread length
15 mm
- Min. temperature
-20 °C
- Max. temperature
+65 °C
IP68
- Spanner size
27 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Manufacturer part #
2024217
- Type
V-TEC L PG16 SGR
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3332525 OBO Bettermann 2024217 Cable gland 1.5 mm Plastic, PA 1 pc(s)
Description
The fastest and most comfortable way to ensure strain relief and leak tightness with cable glands at cable junction boxes and housings: The proven V-TEC VM cable glands from OBO. The protection class IP68 is achieved using the integrated sealing lip and the special OBO lamellae technology. Strain relief and leak tightness have been tested according to DIN EN 50262. The connection thread is metric or PG and thus can be used universally comfortably. Once screwed down, the installation will last forever: The optimum thread adjustment with the correct pitch ensures vibration resistance on a permanent basis. Applications: From private residential use with cable junction boxes to industrial applications in the distribution cabinet.
