OBO Bettermann 5015014 1808 Electrical bonding 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Design = structure fix
- Design = only terminal
- Insulator = No
- Height = 30 mm
- Width = 3000 mm
- Length = 34 mm
- Number of connections round conductor total = 1
- Number of connections round conductor 8 mm = 1
- Number of connections round conductor 10 mm = 0
- Number of connections round conductor 8-10mm = 0
- Number of connections ribbon cables up to 30 mm = 0
- Number of connections ribbon cables up to 40 mm = 1
- Number of ports line up to 6 mm² rigid = 0
- Number of ports line up to 16mm² rigid = 0
- Number of connections cable up to 25 mm² rigid = 8
- Number of connections cable up to 95 mm² rigid = 0
- Material of the contact rail = Steel
- Surface of the contact rail = electroplated with tin
- Material of the clip = brass
- Surface of the clip = Nickel-plated
- Product type
Electrical bonding
- Manufacturer part #
5015014
- Dim
(L x W x H) 34 x 3000 x 30 mm
- Length
34 mm
- Width
3000 mm
- Height
30 mm
- Depth
34 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1965707 OBO Bettermann 5015014 1808 Electrical bonding 1 pc(s)
Description
Bracket and uberleger made of steel, galvanised, terminal bodies and contact strip made of brass, steel screws, hot-dip galvanised
