OBO Bettermann 5015553 1804 Electrical bonding 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Design = structure fix
- Design = only terminal
- Insulator = No
- Height = 9 mm
- Width = 9.3 mm
- Length = 63 mm
- Number of connections round conductor total = 7
- Number of connections round conductor 8 mm = 0
- Number of connections round conductor 10 mm = 0
- Number of connections round conductor 8-10mm = 0
- Number of connections ribbon cables up to 30 mm = 0
- Number of connections ribbon cables up to 40 mm = 0
- Number of ports line up to 6 mm² rigid = 6
- Number of ports line up to 16mm² rigid = 1
- Number of connections cable up to 25 mm² rigid = 0
- Number of connections cable up to 95 mm² rigid = 0
- Material of the contact rail = brass
- Surface of the contact rail = other
- Material of the clip = Steel
- Surface of the clip = galvanically/Electrolytically galvanised
- Product type
Electrical bonding
- Manufacturer part #
5015553
- Dim
(L x W x H) 63 x 9.3 x 9 mm
- Length
63 mm
- Width
9.3 mm
- Height
9 mm
- Depth
63 mm
- Content
1 pc(s)
- Weight
0.03
9.3
Without covering cap
9 mm
Surface mounting fix
63 m
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1964368 OBO Bettermann 5015553 1804 Electrical bonding 1 pc(s)
Description
For bathroom. Contact strip made from nickel-plated brass, screws and bracket made from steel galvanised.
