OBO Bettermann 6109804 Supply unit IP20
EAN:
Part number:
Item no:
Technical specifications
- CEE-socket 16 A: 1 x 16A/415V
- CEE-socket - 32 A: without
- CEE-socket - 63 A: without
- CEE-socket - 125 A: without
- Number of SCHUKO socket outlets: 3
- Other fittings and/or empty slots: 0
- Protection: without
- Residual-current circuit breaker: without
- Material of the Housing: plastic
- Feed/connection possibility: 2 lines (ring line/to loop)
- Handling: suspended
- Military version: no
- Product type
Supply unit
- Outlets
3
- Mounting type
Free suspension
- Factory colour
Multicolour
IP20
- Dim
(L x W x H) 150 cm x 150 mm x 100 mm
- Length
150 cm
- Width
150 mm
- Height
100 mm
- Content
1 pc(s)
- Weight
1160 g
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1962608 OBO Bettermann 6109804 Supply unit IP20
Description
Consisting of casing graphite gray (RAL 9011), suspension eye, grip hook and enclosed wall, without cover plates, weight approx. 0.51 kg. With 4 cover plate and fitted with 1 terminals 3-pole, SCHUKO socket outlets 16 A/250 V AC circuit to 1 pre-wired.
