OBO Bettermann GES2 U 9011 Inset
EAN:
Part number:
Item no:
Technical specifications
- Design cover = rectangular
- Suitable for wet care = No
- Suitable for underfloor channel = Yes
- Suitable for hollow-ground = No
- Suitable for double-Ground = No
- Number of device cup = 1
- Material = polyamide (PA)
- Surface = structured
- With flooring recess = Yes
- The depth of the flooring recess = 5 mm
- Flooring protection frame = Yes
- Min. Installation depth = 70 mm
- Color = black
- RAL-number = 9011
- Length Outer dimension = 194 mm
- Outside width dimension = 118 mm
- Length Installation dimension = 180 mm
- Installation dimensions: width = 104 mm
- Product type
Inset
- Length
194 mm
- Width
118 mm
- Dim
(L x W) 194 mm x 118 mm
- Factory colour
Black
- Recess depth
70 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1958935 OBO Bettermann GES2 U 9011 Inset
Description
Insert for 2 installation devices in 1 GB2 for use in duct systems. With universal mounting bracket. Carpet protection framework, hinged lid and cord outlet made of polyamide.
