OSRAM HOMELIGHTING DALI SWITCH SO 3X6A/24 8X1 LED transformer Constant current 24 V DC DALI 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
DALI switch in such a way 3 X 6 A/24 FS1
- Constant current
- 24 V DC
Technical specifications
- Product type
LED transformer
- Type
Constant current
- Dim
(L x W x H) 96 x 54 x 62 mm
- Factory colour
Colourless
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- LED driver features
DALI
IP20
- Connection
Open end cable
- No. of outputs
3 x
- Weight
155 g
- Width
54 mm
- Height
62 mm
- Length
96 mm
- Max. temperature
+45 °C
- Min. temperature
0 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 758544 OSRAM HOMELIGHTING DALI SWITCH SO 3X6A/24 8X1 LED transformer Constant current 24 V DC DALI 1 pc(s)
User & Safety Instructions
User & Safety Instructions 758544 OSRAM HOMELIGHTING DALI SWITCH SO 3X6A/24 8X1 LED transformer Constant current 24 V DC DALI 1 pc(s)
Description
DALI-controlled switching output for incandescent lamps, QT, OT, PT, HT ballasts · 3 independent relay contacts · Switch contact rating: 6 A resistive load · Supply voltage: 24 V DC · Potential free contacts
This text is machine translated.
This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
