OSRAM HOMELIGHTING OPTOTRONIC DALI LED driver Constant voltage 160 W 24 V dimmable 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
OPTOTRONIC DALI
- Constant voltage
- 24 V
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Dim
(L x W x H) 300 x 50 x 35 mm
- Output voltage (max.)
24 V
- Output voltage (min.)
24 V
- Test mark
BIS | CCC | | EAC | EL | ENEC 10 | RCM | VDE | VDE-ENEC
- Operating voltage
24 V
- LED driver features
dimmable
IP20
- Connection
Screw terminal
- Max. power
160 W
- Input voltage (max.)
276 V
- Min. input voltage
176 V
- Weight
380 g
- Power range
160 W (max)
- Width
50 mm
- Height
35 mm
- Length
300 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2619722 OSRAM HOMELIGHTING OPTOTRONIC DALI LED driver Constant voltage 160 W 24 V dimmable 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2619722 OSRAM HOMELIGHTING OPTOTRONIC DALI LED driver Constant voltage 160 W 24 V dimmable 1 pc(s)
Description
Constant voltage power supplies with DALI. Product features: 4-channel DALI converter. Dimmer range: 0 to 100 % luminous flux Product benefits: Flexible addressing via DALI. Range of applications: Suitable for lights with the protection class I and II. Suitable for independent mounting. Suitable for indoor use. Technical equipment: Suitable for 24 V-LED modules
This text is machine translated.
This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
