PCE Instruments PCE-MPC 20 PCE-MPC 20 RH data logger, Temperature data logger Unit of measurement Temperature, Humidity
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 755.46 / piece)
€ 755.46
plus VAT.
Highlights & Details
PCE Instruments PCE-MPC 20 PCE-MPC 20 RH data logger, Temperature data logger Unit of measurement Temperature, Humidity 0 up to 50 °C 0 up to 100 RH
- 2.8" TFT color LCD display
- 320 x 240 pixels
- Auto switch-off
- Determination of air temperature and air humidity
- Dew point and wet ball temperature
- Extreme value recording
- Records 8 particle sizes
- With camera
Technical specifications
- Dim
(L x W x H) 75 x 57 x 240 mm
- Weight
570 g
- Height
240 mm
- Length
75 mm
- Width
57 mm
- Temperature reading range
0 up to 50 °C
Manufacturer's standards (no certificate)
- Unit of measurement
Temperature
Humidity
- Type
PCE-MPC 20
- Humidity reading range (max.)
100 RH
- Humidity reading range (min.)
0 RH
- Temperature reading range (max.)
50 °C
- Temperature reading range (min.)
0 °C
- Resolution
2.8" 320 x 240 p
- Power supply
Rechargeable battery
- Product type
RH data logger
Documents & Downloads
Datasheet
Datasheet 2299551 PCE Instruments PCE-MPC 20 PCE-MPC 20 RH data logger, Temperature data logger Unit of measurement Temperature, Humidity
User & Safety Instructions
User & Safety Instructions 2299551 PCE Instruments PCE-MPC 20 PCE-MPC 20 RH data logger, Temperature data logger Unit of measurement Temperature, Humidity
Description
The fine dust meter can be used in different areas. The fine dust meter can measure both the particle and the measuring concentration. A fine dust measuring device is used wherever a possible health hazard from fine dust could occur. These include pollution from combustion, manufacturing, energy production, vehicle engine emissions and the pollution generated by the construction industry. In addition to particle counting, the fine dust meter also offers the possibility of determining the mass concentration. In addition to PM2.5 and PM10, particle sizes 0.3, 0.5, 1.0, 2.5, 5.0 and 10 µm can be measured. In addition to the particle sizes, the fine dust meter has sensors for temperature and relative humidity. On the back of the fine dust meter there is a camera, through which measurement data can be linked with image and video material. High levels of air pollution can occur in areas with high traffic volumes. A fine dust measuring device can help to expose these contamination values. Where there is increased air pollution, there may be increased risks of respiratory disease.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1x data logger PCE-PCO 2
- 1x zero filter
- 1 x batteries
- 1x charger
- 1x USB cable
- 1x Mini-Stand
- 1x hard shell case
- 1x user manual.
