Image similar
Pepperl+Fuchs 70114917 Sensor/actuator connector (pre-fab) M8 x 1 0.6 m No. of pins (RJ): 3, 3 1 pc(s)
Product type
Sensor/actuator connector (pre-fab)
Connection side A
M8 socket, right angle
Connection side B
M12 plug, straight
No. of pins
3
3
Cable length
0.6 m
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Type
V3-WM-E2-BK2M-PUR-U-V11-G
- Product type
Sensor/actuator connector (pre-fab)
- Connection side A
M8 socket, right angle
- Connection side B
M12 plug, straight
- No. of pins
3
3
- Cable length
0.6 m
- Jacket material
PUR
- Nominal voltage
24 V DC
- Nominal current
4 A
- Nominal current - rounded value
4 A
- Connector cross-section (max.)
0.34 mm²
- Outside Ø
4.3 mm
- Cross-section (sensor/actuator wiring)
0.34 mm²
- Connection
M8 socket
- Thread type connection side
M8 x 1
- Coding
A
- Contact material
Au
- Contact surface
Au
IP67
IP68
IP69
- Features
Suitable for drag chains
- Min. temperature
-40 °C
- Max. temperature
90 °C
- Seal type
Screw-on
- Manufacturer part #
70114917
- Content
1 pc(s)
- Cable Ø
4.3 mm
- Wireless charging
No
- UKCA
not relevant
