Name: Pepperl+Fuchs 70116171 Sensor lead LiF9YC11Y 4 x 0.34 mm² Black 1 pc(s)
Brand: Pepperl+Fuchs
SKU: 2630204

A black, coiled rubber hose that is ready for use. Ideal for irrigation or industrial applications.

Image similar

Product type

Sensor lead

No. of leads

4 x

Cross section (each core)

0.34 mm²

Cable type

LiF9YC11Y

Cross section

4 x 0.34 mm²

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Sensor lead

Cable type: LiF9YC11Y

No. of leads: 4 x

Cross section (each core): 0.34 mm²

Cross section: 4 x 0.34 mm²

Outside Ø: 4.9 mm

Factory colour: Black

Content: 1 pc(s)

Nominal voltage (details): 300 V

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 10

Halogen-free: Yes

Manufacturer part #: 70116171

Insulation material: PP

Core layout: 42 x 0.1 mm

Min. temperature range (flexible installation): -25 °C

Max. temperature range (flexible installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Max. temperature range (fixed installation): +80 °C

Type: CBL-PUR-U/ABG-BK-04x034-100M

Wireless charging: No

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2630204 Pepperl+Fuchs 70116171 Sensor lead LiF9YC11Y 4 x 0.34 mm² Black 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2630204 Pepperl+Fuchs 70116171 Sensor lead LiF9YC11Y 4 x 0.34 mm² Black 1 pc(s)

Description

Cable, PUR/PP, 4-wire black, shielded, UL approved, Suitable for tow chains, length 100 m.

This text is machine translated.

Features

Electrical DataOperating voltage max. 300 VComplianceProtection class EN 60529FLAMMABILITY UL 1581; DIN EN 60332-2-2Halogen-free: DIN VDE 0472-815Resistance to microbene: EN 50363Resistance to hydrolysis: EN 50363Approvals and certificatesUL approval: CURus AWM 20549/10493 80°C 300V FT2Ambient conditionsAmbient temperature Cable, fixed: -40 ... 80 °C (-40 ... 176 °F) Cable, movable: -25 ... 80 °C (-13 ... 176 °F)Pollution level 3Mechanical data:Cable: According to IEC/EN 60228 (DIN VDE 0295) class 6 Sheath diameter 4.9 mm ± 0.15 mm Bending radius: > 10 x cable diameter, moving | > 5 x cable diameter, fixed laid Sheath adhesive seat: Max. 60 N / 100 mm Sheath color: Black (similar to RAL 9005) Core number: 4 Wire cross-section 0.34 mm2 Wire color: Wire 1: brown | Wire 2: White | Wire 3: Blue | Wire 4: Black Core construction: 42 x 0.1 mm Ø Shield: Copper braid, tin-plated, 85% coverage Length: 100 m Mass: 37.4 kg/km. Cable short code: Li F 9Y C11Y 4 x 0.34Drag chain capability Trailing chain cycles: Min. 2000000 Travel speed: Max. 3 m/s Travel distance: Max. 5 m Acceleration: Max. 5 m/s2materialHalogen-free: YesCable Sheath: PURE on polyether basis Wire insulation: PP UV resistance: Yes Chemical resistance: Good Oil resistance: Yes Coolant resistance: Yes Microbe resistance: Yes Resistance to hydrolysis: Yes FT2 combustibility
