Name: Pfannenberg Light LED PMF LED-HI 21155637007 Blue Blue Flash, Flasher 24 V DC
Brand: Pfannenberg
SKU: 2890818
Availability: BackOrder

Blue warning light with a transparent housing, mounted on a metal bracket. Used for safety and alarm systems.

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Fri 6 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 505.00 / piece)

€ 505.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Number of modes: 3
Version: Other
Function flashing light: Yes
Flash function: Yes
Continuous light function: No.
Black enclosure
Calotte color: Blue
Power: 6.8 W
Bulb: LED not replaceable
Mounting type: Other
Nominal voltage: 24 V/DC
Protection class (IP) IP55
Solar powered: No.
Standby time of up to 0 hrs
Current consumption: 0.8 A
Ambient temperature: -40 °C - 55 °C
Housing material: Plastic

Product type: Light

Operating voltage: 24 V DC

Max. current consumption: 0.8 A

Colour: Blue

(Ø): 177 mm

Height: 185 mm

Features: LED

: IP55

Dim: (Ø x H) 177 mm x 185 mm

Factory colour: Blue

Case colour: Black

Lighted picture: Flash

Material: Plastic

Signal type: Flash
Flasher

Type: PMF LED-HI

Light intensity: 315 cd

Calotte colour: Blue

Max. temperature: 55 °C

Min. temperature: -40 °C

: 6.8 W

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2890818 Pfannenberg Light LED PMF LED-HI 21155637007 Blue Blue Flash, Flasher 24 V DC

User & Safety Instructions

User & Safety Instructions 2890818 Pfannenberg Light LED PMF LED-HI 21155637007 Blue Blue Flash, Flasher 24 V DC

Description

Extremely bright all-round flash light with blue cover and Fresnel lens
- 3 different signal modes adjustable: Flash, flash, rotating mirror effect
- Standard with switch-on current limitation and wide-range power supply 10 - 30 V DC
- For signaling hazardous conditions in safety-relevant applications such as process and plant safety
- Low power consumption, high reliability and long service life through the use of state-of-the-art electronic components - without replacement of mechanical or electrical wearing parts
- Up to 2 out of 4 quadrants can be switched off, saving energy and signaling
- Multiple mounting options - directly with supplied flat seal (DM) or with a stainless steel angle (WM)
- 315 CD, automatically reducible (day/night operation)
- Life of the bulb: > 50000h
- Maximum visibility: 411 m.
- Degree of protection: IP 55 (vertical mounting)
- Dimensions: 177 mm diameter x 185 mm (depending on the type of installation)
- Operating temperature: -40C - +55C

This text is machine translated.
