Image similar
Phoenix Contact 1046968 Distribution block Violet 20 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Distribution block
Nominal current - rounded value
17.5 A
Content
20 pc(s)
Pins per row
13
Datasheet (PDF)
Technical specifications
- Cover plate required: No.
- Number of clamping points per level: 13
- Rated current In:17.5 A.
- Flammability class of insulation material according to UL94: V0
- Floors bridged: Yes
- Material of the insulating body: Other
- Packaging type
Piece
- Product type
Distribution block
- Pins per row
13
- Number of pins
13
- Factory colour
Violet
- Nominal current
17.5 A
- Nominal current - rounded value
17.5 A
- Nominal voltage
450 V
- Manufacturer part #
1046968
- Content
20 pc(s)
- Type
PTFIX 4/12X1,5 VT
- Dim
(W x H x D) 31.4 x 21.6 x 17.7 mm
- Width
31.4 mm
- Height
21.6 mm
- Flammability rating
V0
- Depth
17.7 mm
- Rated voltage
450 V
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3562324 Phoenix Contact 1046968 Distribution block Violet 20 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3562324 Phoenix Contact 1046968 Distribution block Violet 20 pc(s) Piece
Description
Distributor block, basic terminal with infeed, nominal voltage: 450 V, nominal current: 17.5 A, number of connections: 13, tap , cross section: 0.14 mm² - 2.5 mm², push-in connection, collective connection , rated cross-section: 4 mm², cross-section: 0.2 mm² - 6 mm², mounting type: Snap-on mounting rail adapter, direct mounting with flange, flying, color: Violet
