Phoenix Contact 1072486 PCB pin header Total number of pins 4 No. of rows 1 50 pc(s) Carton
Product type
PCB pin header
Total no. of pins
4
CS
5 mm
Content
50 pc(s)
Packaging type
Carton
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
PCB terminal strip
- Total number of pins 4
- No. of rows 1
- Content 50 pc(s)
Technical specifications
- Pollution level: 2
- Over voltage category III
- Packaging type
Carton
- Product type
PCB pin header
- Total no. of pins
4
- Features
+ locking mechanism
- Total number of pins
4
- No. of rows
1
- CS
5 mm
- Connection
Soldering
- Case material
PA
- Manufacturer part #
1072486
- Content
50 pc(s)
- Type
ICC25-H/4L5,0-9005
- Board contact surface
Tin
- Connector contact surface
Tin
- Number of pins
4
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3562762 Phoenix Contact 1072486 PCB pin header Total number of pins 4 No. of rows 1 50 pc(s) Carton
User & Safety Instructions
User & Safety Instructions 3562762 Phoenix Contact 1072486 PCB pin header Total number of pins 4 No. of rows 1 50 pc(s) Carton
Description
PCB baseboard, rated cross-section: 2.5 mm², Colour: Black, rated current: 16 4 A, rated voltage (III/2): 320 V, contact surface: Sn, contact type: Pin, number of potential: 4, number of rows: 5, number of connections: 4, product family: IC..-H/..L5.0, grid dimension: 1 mm, mounting: Wave soldering, pin layout: Linear pinning, pin layout: Pin length [P]: 3.5 mm, number of solder pins per potential: 1, plug system: ICC 2.5, orientation plug face: standard, locking: latch locking, mounting type: without, Packaging type: cardboard packaging, items with left side pin outlet
