1/3
Image similar
Phoenix Contact 1076600 Cable gland M25 x 1.5 Plastic, PA, CR Black 1 pc(s)
Product type
Cable gland
External thread
M25 x 1.5
Material
Plastic
PA
CR
Clamp Ø
3 mm
Terminal Ø (max.)
7 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 10
Multiple: 1
Total (€ 10.99 / piece)
€ 109.90
incl. VAT
14-day return policy included
Technical specifications
- Hexagonal corner dimensions 37.4 mm
- Number of lines: 1
- Product type
Cable gland
- Factory colour
Black
- External thread
M25 x 1.5
- Bore diameter
25.1 mm - 25.2 mm
- Torque
5 Nm - 7.5 Nm
- Material
Plastic
PA
CR
- Clamp Ø
3 mm
- Terminal Ø (max.)
7 mm
- Thread length
10 mm
- Length
47 mm
- Width
37.7 mm
- Min. temperature
-20 °C
- Max. temperature
+100 °C
IP66
- Spanner size
33 mm
- Dimensions
31.7 mm x 47 mm
- Halogen-free
No
- Content
1 pc(s)
- Dim
(L x W) 47 mm x 37.7 mm
- Manufacturer part #
1076600
- Type
G-CCS-M25-M66N-PNES-BK
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2209096 Phoenix Contact 1076600 Cable gland M25 x 1.5 Plastic, PA, CR Black 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2209096 Phoenix Contact 1076600 Cable gland M25 x 1.5 Plastic, PA, CR Black 1 pc(s)
Description
Plastic cable gland with slotted seal, for plug connector with pre-assembled cable, IP66, connection thread M25, clear width: 18.2 mm
This text is machine translated.
This text is machine translated.
