Phoenix Contact 1410712 REDUC-K-KV-M32/M25 BK M32 M25 Polyimide Black 10 pc(s)
Internal thread
M25
External thread
M32
Material
Polyimide
Factory colour
Black
Spanner size
36 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Length without connection thread: 6 mm
- Diameter of connection thread: 32 mm
- Hexagonal corner dimensions 40 mm
- Tightening torque: 3.5 Nm - 5 Nm
- Internal thread
M25
- Factory colour
Black
- External thread
M32
- Spanner size
36 mm
- Thread length
10 mm
- Length
16 mm
IP65
- Min. temperature
-30 °C
- Max. temperature
+100 °C
- Material
Polyimide
- Halogen-free
No
- Content
10 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
1410712
- Type
REDUC-K-KV-M32/M25 BK
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2136847 Phoenix Contact 1410712 REDUC-K-KV-M32/M25 BK M32 M25 Polyimide Black 10 pc(s)
User & Safety Instructions
User & Safety Instructions 2136847 Phoenix Contact 1410712 REDUC-K-KV-M32/M25 BK M32 M25 Polyimide Black 10 pc(s)
Description
Reduction adapter made of plastic, M32 to M25, including O-ring
