Phoenix Contact 1410738 REDUC-K-KV-M40/M32 BK M40 M32 Polyimide Black 10 pc(s)
Internal thread
M32
External thread
M40
Material
Polyimide
Factory colour
Black
Spanner size
46 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Length without connection thread: 6 mm
- Diameter of connection thread 40 mm
- Hexagonal corner dimensions 50.5 mm
- Tightening torque: 5 Nm - 7.5 Nm
- Internal thread
M32
- Factory colour
Black
- External thread
M40
- Spanner size
46 mm
- Thread length
10 mm
- Length
16 mm
IP65
- Min. temperature
-30 °C
- Max. temperature
+100 °C
- Material
Polyimide
- Halogen-free
No
- Content
10 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
1410738
- Type
REDUC-K-KV-M40/M32 BK
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2136744 Phoenix Contact 1410738 REDUC-K-KV-M40/M32 BK M40 M32 Polyimide Black 10 pc(s)
User & Safety Instructions
User & Safety Instructions 2136744 Phoenix Contact 1410738 REDUC-K-KV-M40/M32 BK M40 M32 Polyimide Black 10 pc(s)
Description
Reduction adapter made of plastic, M40 to M32, including O-ring
