Phoenix Contact 1411193 Cable gland with strain relief Plastic Silver 1 pc(s)
Product type
Cable gland
Material
Plastic
Clamp Ø
24 mm
Terminal Ø (max.)
35 mm
Features
with strain relief
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Type of seal: Sealing ring
- Design: Straight
- Bend protection: No.
- Pressure balancing: No.
- Operating temperature -40°C
- EMC type: No.
- Explosion-tested version: No.
- Cable connection: No.
- For reinforced cables: No.
- For Ex-zone gas: Without
- For Ex-Zone Dust: Without
- Suitable for cable diameter 24-35 mm
- Shielded: No.
- Thread type: Metric
- Halogen-free: No.
- Snap into opening: No.
- Multiple seal insert: No.
- With counter nut: No.
- With strain relief: Yes
- Surface protection: Untreated
- Wrench width: 55 mm
- Hexagonal width 60 mm
- Separable screw connection: No.
- Material quality: Polyamide (PA)
- Product type
Cable gland
- Features
with strain relief
- Factory colour
Silver
- Material
Plastic
- Clamp Ø
24 mm
- Terminal Ø (max.)
35 mm
- Thread length
9 mm
- Min. temperature
-40 °C
- Max. temperature
100 °C
IP68
- Spanner size
55 mm
- Halogen-free
No
- Content
1 pc(s)
- Manufacturer part #
1411193
- Type
G-INSEC-M50-L68N-NCRS-S
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3452518 Phoenix Contact 1411193 Cable gland with strain relief Plastic Silver 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3452518 Phoenix Contact 1411193 Cable gland with strain relief Plastic Silver 1 pc(s)
Description
Cable gland, screw connection material: Brass, nickel plated, application: EMC, cable external diameter 24 mm ... 35 mm, shielding: Yes, connection thread: M50 x 1.5, color: Silver colored, with O-ring
This text is machine translated.
