Phoenix Contact 1415186 MG-INC-M16-S67L-PTES-LG Membrane gland M16 M16 Polypropylene Light grey 20 pc(s)
Product type
Membrane gland
External thread
M16
Size
M16
Material
Polypropylene
Outside Ø
16 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Length without connection thread: 7 mm
- Diameter of connection thread: 16 mm
- Hexagonal corner dimensions 32 mm
- Screw connection material: Polypropylene
- Material seal: TPE
- Diameter through hole: 16 mm - 16.7 mm
- External diameter of the cable: 4 mm - 10 mm
- Product type
Membrane gland
- Outside Ø
16 mm
- Factory colour
Light grey
- External thread
M16
- Size
M16
- Spanner size
32 mm
- Thread length
8 mm
- Clamp Ø
4 mm
- Terminal Ø (max.)
10 mm
- Length
15 mm
IP67
IP66
- Min. temperature
-40 °C
- Max. temperature
+65 °C
- Material
Polypropylene
- Content
20 pc(s)
- Dim
7
- Dimensions
7 mm
- Manufacturer part #
1415186
- Type
MG-INC-M16-S67L-PTES-LG
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2209208 Phoenix Contact 1415186 MG-INC-M16-S67L-PTES-LG Membrane gland M16 M16 Polypropylene Light grey 20 pc(s)
User & Safety Instructions
User & Safety Instructions 2209208 Phoenix Contact 1415186 MG-INC-M16-S67L-PTES-LG Membrane gland M16 M16 Polypropylene Light grey 20 pc(s)
Description
Screw connection, material Screw connection: Polypropylene, Application: Standard, cable outer diameter 4 mm ... 10 mm, shielding: no, connection thread: M16, color: Light gray
