Phoenix Contact 1436268 PCB pin header Total number of pins 2 No. of rows 1 250 pc(s)
Product type
PCB pin header
Total no. of pins
2
CS
3.81 mm
Content
250 pc(s)
Total number of pins
2
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
PCB terminal strip
- Total number of pins 2
- No. of rows 1
- Content 250 pc(s)
Technical specifications
- Number of plug contact rows: 1
- Tape type: Cardboard (for SMD)
- Design of the electrical connection: Other
- Mounting method: Other
- Rated current In:8 A.
- Operating temperature 40 °C
- Flammability class of insulation material according to UL94: V0
- Diameter connection pin 1.2 mm
- Pin contact type
- Length of the pin 3.4 mm
- Grid dimension of the connections 3.81 mm
- Contact spacing 3.81 mm
- Connector design: Fixed connector
- Pollution level: 2
- Material of the contact coating: Tin
- Material of the insulating body: Other
- Over voltage category III
- Product type
PCB pin header
- Total no. of pins
2
- Total number of pins
2
- No. of rows
1
- CS
3.81 mm
- Connection
COMBICON
- Case material
PA
- Manufacturer part #
1436268
- Content
250 pc(s)
- Max. temperature
100 °C
- Min. temperature
-40 °C
- Type
MCV 1,5/ 2-G-3,81 OG
- Connector contact surface
Tin
- Number of pins
2
- Case colour
Orange
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3585392 Phoenix Contact 1436268 PCB pin header Total number of pins 2 No. of rows 1 250 pc(s)
User & Safety Instructions
User & Safety Instructions 3585392 Phoenix Contact 1436268 PCB pin header Total number of pins 2 No. of rows 1 250 pc(s)
Description
PCB baseboard, rated cross-section: 1.5 mm², Colour: Orange, rated current: 8 A, contact surface: Sn, Contact type: pin, number of rows: 1, number of poles: 2, product family: MCV 1.5/...-G, pitch: 3.81 mm, mounting: wave soldering, Pin layout: linear pinning, pin length [P]: 3.4 mm, number of soldering pins per potential: 1, connector system: COMBICON MC 1.5, mating face: standard, locking: without, mounting type: without, packaging type: packed in carton
