Phoenix Contact 1822752 PCB terminal 1.5 mm² Number of pins 2 Black 350 pc(s) Carton
Packaging type
Carton
Product type
PCB terminal
CS
3.5 mm
Pins per row
2
Number of pins
2
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Packaging type
Carton
- Type
SPT-THR 1,5/ 2-H-3,5 P26
- Product type
PCB terminal
- CS
3.5 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
SPT
- Connection
Push-in spring-loaded terminal
- Nominal current
17.5 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
17.5 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (max.)
1.5 mm²
- Contact material
Tin
- Factory colour
Black
- Manufacturer part #
1822752
- Content
350 pc(s)
- Height
10.3 mm
- UKCA
yes
