Image similar
Phoenix Contact 1891085 PCB terminal 0.5 mm² Number of pins 4 Green 50 pc(s)
Product type
PCB terminal
CS
3.5 mm
Pins per row
4
Number of pins
4
Connection
Push-in spring-loaded terminal
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
- Content 50 pc(s)
Technical specifications
- Type
FK-MPT 0,5/ 4-3,5
- Product type
PCB terminal
- Features
+ push-in spring bracket
- CS
3.5 mm
- No. of rows
1
- Pins per row
4
- Number of pins
4
- Connection
Push-in spring-loaded terminal
- Nominal current
4 A
- Cross section (flexible) (min.)
0.5 mm²
- Nominal current - rounded value
4 A
- Cross section (inflexible) (min.)
0.12 mm²
- Cross section (flexible) (max.)
0.5 mm²
- Cross section (inflexible) (max.)
0.5 mm²
- Connector orientation
Perpendicular (to the PCB)
- Contact material
Tin
- Factory colour
Green
- Manufacturer part #
1891085
- Content
50 pc(s)
- Height
13 mm
- Length
3.5 mm
- Case colour
Green
- UKCA
yes
