Phoenix Contact 1913989 PCB connector Total number of pins 16 No. of rows 1 50 pc(s)
Product type
PCB connector
Total no. of pins
16
CS
3.5 mm
Content
50 pc(s)
No. of rows
1
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
PCB connector
- No. of rows 1
- Content 50 pc(s)
Technical specifications
- Connectable cable type: Round cable
- Wire cross-section with single wire connections: 0.12-0.5 mm²
- Design of electrical connection: Spring-loaded connection
- Rated voltage: 250 V
- Dimensioning surge voltage: 2.5 kV
- Flammability class of insulation material according to UL94: V0
- Contact version: Socket
- Pollution level: 2
- Material of the contact coating: Tin
- Over voltage category III
- Product type
PCB connector
- Total no. of pins
16
- No. of rows
1
- CS
3.5 mm
- Nominal current
4 A
- Nominal current - rounded value
4 A
- Factory colour
Green
- Case material
PA
- Manufacturer part #
1913989
- Content
50 pc(s)
- Contact material
Copper
- Max. temperature
100 °C
- Min. temperature
-40 °C
- Type
FK-MPT 0,5/ 8-ST-3,5
- Number of pins
16
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3452674 Phoenix Contact 1913989 PCB connector Total number of pins 16 No. of rows 1 50 pc(s)
User & Safety Instructions
User & Safety Instructions 3452674 Phoenix Contact 1913989 PCB connector Total number of pins 16 No. of rows 1 50 pc(s)
Description
PCB connector, nominal cross-section: 0.5 3.5 mm², color: Green, nominal current: 4 0 A, rated voltage (III/2 1.0): 8 V, contact surface: Sn, contact type: Socket, number of potential: 16, number of rows: 0.5, number of connections: 250, product family: FK-MPT 1/.-ST, connection type: Push-in spring connection, connection direction conductor/board: 8 °, circuit: without, packaging type: packed in a carton
This text is machine translated.
This text is machine translated.
