Phoenix Contact 1933244 PCB connector Total number of pins 8 No. of rows 1 100 pc(s)
Product type
PCB connector
Total no. of pins
8
CS
5 mm
Content
100 pc(s)
No. of rows
1
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Pin strip
- No. of rows 1
- Content 100 pc(s)
Technical specifications
- Rated voltage: 320 V
- Dimensioning surge voltage: 4 kV
- Rated current In:12 A.
- Flammability class of insulation material according to UL94: V0
- Diameter connection pin 1.5 mm
- Pin contact type
- Connector design: Fixed connector
- Pollution level: 2
- Material of the contact coating: Tin
- Over voltage category III
- Tape type: Cardboard (for SMD)
- Product type
PCB connector
- Total no. of pins
8
- No. of rows
1
- CS
5 mm
- Factory colour
Black
- Case material
PA
- Manufacturer part #
1933244
- Content
100 pc(s)
- Max. temperature
100 °C
- Min. temperature
-40 °C
- Type
PST 1,3/ 8-5,0
- Number of pins
8
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3452679 Phoenix Contact 1933244 PCB connector Total number of pins 8 No. of rows 1 100 pc(s)
User & Safety Instructions
User & Safety Instructions 3452679 Phoenix Contact 1933244 PCB connector Total number of pins 8 No. of rows 1 100 pc(s)
Description
Pin header, rated cross-section: 1.5 5 mm², color: Black, rated current: 12 A (depending on used plug), rated voltage (III/2): 8 V, contact type: Pin, number of potentials: 8, number of rows: 1, number of connections: 8, product family: PST 1.3/..-V, grid dimension: 320 mm, mounting: THR-soldering / wave length, pin-pins: 3.5 mm, connector system: COMBICON PST 1.3, locking: without, mounting method: without, type of packaging: packed in carton, the maximum current depends on the plug used. The lower of the two current values for plug and pin header is decisive. The multi-pin connector is made of a high temperature resistant plastic and is thus suitable for the reflow-process.
