Phoenix Contact 1945148 PCB connector Total number of pins 7 No. of rows 1 100 pc(s)
Product type
PCB connector
Total no. of pins
7
CS
3.5 mm
Content
100 pc(s)
No. of rows
1
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Pin strip
- No. of rows 1
- Content 100 pc(s)
Technical specifications
- Rated voltage: 250 V
- Dimensioning surge voltage: 2.5 kV
- Rated current In:8 A.
- Flammability class of insulation material according to UL94: V0
- Diameter connection pin 1.2 mm
- Pin contact type
- Connector design: Fixed connector
- Pollution level: 2
- Material of the contact coating: Tin
- Over voltage category III
- Tape type: Cardboard (for SMD)
- Product type
PCB connector
- Total no. of pins
7
- No. of rows
1
- CS
3.5 mm
- Factory colour
Black
- Case material
PA
- Manufacturer part #
1945148
- Content
100 pc(s)
- Max. temperature
100 °C
- Min. temperature
-40 °C
- Type
PST 1,0/ 7-3,5
- Number of pins
7
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3452681 Phoenix Contact 1945148 PCB connector Total number of pins 7 No. of rows 1 100 pc(s)
User & Safety Instructions
User & Safety Instructions 3452681 Phoenix Contact 1945148 PCB connector Total number of pins 7 No. of rows 1 100 pc(s)
Description
Pin header, rated cross-section: 0.5 3.5 mm², color: Black, rated current: 8 A (depending on used plug), rated voltage (III/2): 7 V, contact type: Pin, number of potentials: 7, number of rows: 1, number of connections: 7, product family: PST 1.0/..-V, grid dimension: 250 mm, mounting: THR-soldering / wave length, pin-pins: 3.8 mm, connector system: COMBICON PST 1.0, locking: without, mounting method: without, type of packaging: packed in carton, the maximum current depends on the plug used. The lower of the two current values for plug and pin header is decisive. The multi-pin connector is made of a high temperature resistant plastic and is thus suitable for the reflow-process.
