Image similar
PTR Hartmann PCB connector Total number of pins 11 Contact spacing: 3.5 mm 54541116401D 1 pc(s) Piece
Product type
PCB connector
Connector type
PCB connector
CS
3.5 mm
Total number of pins
11
Packaging type
Piece
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
- Content: 1 pc(s)
- Total number of pins: 11
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
PCB connector
- Connector type
PCB connector
- Features
+ snap-in flange
- CS
3.5 mm
- Total number of pins
11
- Content
1 pc(s)
- Stripping length (max.)
10.0 mm
- Connection
Push-in spring-loaded terminal
- Case material
PA 6.6
- Manufacturer part #
54541116401D
- Factory colour
Basalt grey
- Insulation material
UL 94 V0 standard
- Connector contact surface
Tin plated
- Length
48.30 mm
- max. cross section
1.5 mm²
- Min. cross section
0.2 mm²
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
AK4541/11FRKD-3.5-BASALTGRAU
Documents & Downloads
Datasheet
Datasheet 3590312 PTR Hartmann PCB connector Total number of pins 11 Contact spacing: 3.5 mm 54541116401D 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3590312 PTR Hartmann PCB connector Total number of pins 11 Contact spacing: 3.5 mm 54541116401D 1 pc(s) Piece
Description
this an historic product which is not available, thus not updated anymore
