1/2
Image similar
PTR Hartmann PCB connector Total number of pins 11 Contact spacing: 5 mm 54951112401D 1 pc(s)
Product type
PCB connector
Connector type
PCB connector
CS
5 mm
Total number of pins
11
Features
encodable
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
- Content: 1 pc(s)
- Total number of pins: 11
Our service for you
Technical specifications
- Product type
PCB connector
- Connector type
PCB connector
- Features
encodable
- CS
5 mm
- Total number of pins
11
- Content
1 pc(s)
- Stripping length (max.)
12.0 mm
- Connection
Push-in spring-loaded terminal
- Case material
PA 6.6
- Manufacturer part #
54951112401D
- Factory colour
Basalt grey
- Contact material
Copper alloy
- Length
65.00 mm
- max. cross section
2.5 mm²
- Min. cross section
0.2 mm²
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
AK4951/11FKD-5.0-BASALTGRAU
Documents & Downloads
Datasheet
Datasheet 3590375 PTR Hartmann PCB connector Total number of pins 11 Contact spacing: 5 mm 54951112401D 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3590375 PTR Hartmann PCB connector Total number of pins 11 Contact spacing: 5 mm 54951112401D 1 pc(s)
Description
this an historic product which is not available, thus not updated anymore
