1/2
Image similar
PTR Hartmann PCB connector Total number of pins 7 Contact spacing: 5.08 mm 54951072421D 1 pc(s) Piece
Product type
PCB connector
Connector type
PCB connector
CS
5.08 mm
Total number of pins
7
Packaging type
Piece
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
- Content: 1 pc(s)
- Total number of pins: 7
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
PCB connector
- Connector type
PCB connector
- Features
+ push-in spring bracket
- CS
5.08 mm
- Total number of pins
7
- Content
1 pc(s)
- Stripping length (max.)
12.0 mm
- Connection
Push-in spring-loaded terminal
- Case material
PA 6.6
- Manufacturer part #
54951072421D
- Factory colour
Basalt grey
- Contact material
Copper alloy
- Length
45.56 mm
- max. cross section
2.5 mm²
- Min. cross section
0.2 mm²
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
AKZ4951/7FKD-5.08-BASALTGRAU
Documents & Downloads
Datasheet
Datasheet 3590377 PTR Hartmann PCB connector Total number of pins 7 Contact spacing: 5.08 mm 54951072421D 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3590377 PTR Hartmann PCB connector Total number of pins 7 Contact spacing: 5.08 mm 54951072421D 1 pc(s) Piece
Description
this an historic product which is not available, thus not updated anymore
