PTR Hartmann Pin strip (standard) Total number of pins 10 Contact spacing: 3.81 mm 51570106021D 1 pc(s) Piece
Product type
Pin strip (standard)
No. of rows
2
CS
3.81 mm
Total number of pins
10
Packaging type
Piece
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
- Content: 1 pc(s)
- No. of rows: 2
- Total number of pins: 10
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
Pin strip (standard)
- No. of rows
2
- Features
+ sleeve
- CS
3.81 mm
- Total number of pins
10
- Content
1 pc(s)
- Connection
Pin strip
- Case material
PBT
- Manufacturer part #
51570106021D
- Factory colour
Green
- Contact material
Copper alloy
- Length
48.49 mm
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
STLZ1570/10F-3.81-H-GRÜN
Documents & Downloads
Datasheet
Datasheet 3590527 PTR Hartmann Pin strip (standard) Total number of pins 10 Contact spacing: 3.81 mm 51570106021D 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3590527 PTR Hartmann Pin strip (standard) Total number of pins 10 Contact spacing: 3.81 mm 51570106021D 1 pc(s) Piece
Description
this an historic product which is not available, thus not updated anymore
