PTR Hartmann Pin strip (standard) Total number of pins 10 Contact spacing: 5 mm 50950105389D 1 pc(s) Piece
Product type
Pin strip (standard)
Connector type
PCB connector
CS
5 mm
Total number of pins
10
Packaging type
Piece
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
- Content: 1 pc(s)
- Total number of pins: 10
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
Pin strip (standard)
- Connector type
PCB connector
- Features
High current
- CS
5 mm
- Total number of pins
10
- Content
1 pc(s)
- Connection
THR
- Case material
PPA
- Manufacturer part #
50950105389D
- Factory colour
Black
- Contact material
Copper alloy
- Length
50.00 mm
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
STL950/10-5.0-V-P2.6-BK-HC-HT
Documents & Downloads
Datasheet
Datasheet 3590686 PTR Hartmann Pin strip (standard) Total number of pins 10 Contact spacing: 5 mm 50950105389D 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3590686 PTR Hartmann Pin strip (standard) Total number of pins 10 Contact spacing: 5 mm 50950105389D 1 pc(s) Piece
Description
this an historic product which is not available, thus not updated anymore
