PTR Hartmann Pin strip (standard) Total number of pins 11 Contact spacing: 3.81 mm 51570115021D 1 pc(s) Piece
Product type
Pin strip (standard)
CS
3.81 mm
Total number of pins
11
Packaging type
Piece
Features
closed
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
- Content: 1 pc(s)
- Total number of pins: 11
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
Pin strip (standard)
- Features
closed
- CS
3.81 mm
- Total number of pins
11
- Pin Ø
1.2 mm
- Content
1 pc(s)
- Case material
PBT
- Manufacturer part #
51570115021D
- Factory colour
Green
- Contact material
Copper alloy
- Length
43.30 mm
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
STLZ1570/11G-3.81-H-GRÜN
Documents & Downloads
Datasheet
Datasheet 3590516 PTR Hartmann Pin strip (standard) Total number of pins 11 Contact spacing: 3.81 mm 51570115021D 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3590516 PTR Hartmann Pin strip (standard) Total number of pins 11 Contact spacing: 3.81 mm 51570115021D 1 pc(s) Piece
Description
this an historic product which is not available, thus not updated anymore
