Image similar
RIDI 0209501 Flush mount Motion detector and brightness sensor
EAN:
Part number:
Item no:
Technical specifications
- Height: 48 mm
- Design: Presence detectors
- Mounting type: Flush-mounted
- Material: Plastic
- Colour: white
- Surface protection: Untreated
- Transparent: No.
- Design of surface: Matt
- Diameter 52 mm
- KNX bus system: No.
- Bus system LON: No.
- Bus system Powernet: No.
- Other bus systems: DALI
- Number of channels: 1
- Bus system KNX radio: No.
- Bus system wireless bus: No.
- Wireless bidirectional: No
- With bus connection: Yes
- Suitable for wall mounting: No.
- Suitable for ceiling mounting: Yes
- With connection cable: No.
- Material quality: Other
- RAL number (similar): 9010
- Response brightness adjustable: No.
- Optimum mounting height 2.5 m.
- Max. Range to one side: 4.5 m.
- Max. Range: Front 6 m
- Capturing field Diameter on floor: 9 m.
- Operating mode switch: No.
- Staircase monitoring: No.
- Min Switch-on time 1 seconds
- Max. duty cycle 30 min
- Low-level detection/back field monitoring: Yes
- Teach-Function for Response Brightness: No.
- Animal slope: No.
- Extension input: No.
- Switch-off delay, self-learning: No.
- Rear field monitoring: No.
- With acoustic sensor: No.
- DALI-2 certified: Yes
- Product type
Motion detector and brightness sensor
6 m
- Mounting type
Flush mount
- Similar RAL
9010
- Height
48 mm
- (Ø)
52 mm
- Dim
(Ø x H) 52 mm x 48 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3549750 RIDI 0209501 Flush mount Motion detector and brightness sensor
Description
Combined DALI-2 light and presence sensor. Can be used as a presence sensor and/or light sensor. Plastic, white, similar to RAL 9010. Suitable for ceiling mounting. Max. Mounting height 5 m. For connecting to central control/application controller. With light and motion detector. Detection range transverse Ø 9 m, detection field 63 m². Sensor values are provided on the DALI-2 instances in accordance with IEC 62386 Part 303 and 304 on the DALI bus.
