Robotis Servo motor MBS-ANT-12
EAN:
Part number:
Item no:
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 1,675.00 / piece)
€ 1,675.00
incl. VAT
Only available for business customers
14-day return policy includedTechnical specifications
- Resolution 526 374 U (0.0006°)
- Weight 0.27 kg
- Dimensions 42 x 42 x 72 mm
- Operating voltage 24 V.
- Maximum speed 26U/M
- Engine type: BLDC (Maxon)
- Power consumption: Up to 0.6 A
- Torque: 1.7 Nm
- Reduction ratio 257:1
- Interface: RS485 (half duplex, 8bit, 1 stop bit, No parity)
- Operating temperature: -5 °C to + +55 °C.
- Operating modes: Torque, velocity, position, extended position and PWM control
- Product type
Servo motor
- Length
42 mm
- Width
42 mm
- Manufacturer part #
MBS-ANT-12
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3204962 Robotis Servo motor MBS-ANT-12
Description
The ROBOTIS DYNAMIC Pro+ servo motors have different performance values, dimensions and interfaces, offering a wide variety of options. The Dynamic Pro+ M42P-010-S260-R has a planetary gear with integrated encoder, allowing up to 526 374 steps per revolution. In addition, the following special functions have been added to the Dynamixel Pro Servo motor:
Power sensor for torque adjustment
Control algorithm for speed, position and amplification regulation
PID controller for internal position control and correction
The communication between the servo motor and the control electronics can take place either by means of the ROBOTIS Dynamikel U2D2, the ROBOTIS OpenCR1.0 development board or many other Dynamik Pro / RS485 compatible control units. However, it must be noted that the operating voltage lies at 24 volt contrary to the Dynamxel AX/MX series.
This text is machine translated.
Power sensor for torque adjustment
Control algorithm for speed, position and amplification regulation
PID controller for internal position control and correction
The communication between the servo motor and the control electronics can take place either by means of the ROBOTIS Dynamikel U2D2, the ROBOTIS OpenCR1.0 development board or many other Dynamik Pro / RS485 compatible control units. However, it must be noted that the operating voltage lies at 24 volt contrary to the Dynamxel AX/MX series.
This text is machine translated.
Scope of delivery
- DYNAMIC M42P-010-S260-R
- 2x X4P 600 mm data & power cable
- 20x WB M3x8mm
