Rohde LF-01.108.01 Grab rail Silver (L x W x H) 120 x 27 x 60 mm 2 pc(s)
Product type
Grab rail
Material
Aluminium
Dim
(L x W x H) 120 x 27 x 60 mm
Width
27 mm
Height
60 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Rohde Aluminum bar handle, for front mounting, anodized in nature
- Content 2 pcs.
Technical specifications
- Surface treatment: Anodized
- Material (material): AlMgSi 0.5
- Manufacturer color: silver
- Mounting method: c:Round bore
- Series name: LF-01
- Handle type (series): Grip series LF-01 Bar grip
- Hole diameter: M4
- Dim
(L x W x H) 120 x 27 x 60 mm
- Product type
Grab rail
- Material
Aluminium
- Width
27 mm
- Height
60 mm
- Length
120 mm
- Hole spacing
108 mm
- Factory colour
Silver
- Content
2 pc(s)
- Hole Ø
4 mm
- Max. load capacity
500 N
- Type
LF-01.108.01
Documents & Downloads
Datasheet
Datasheet 2343736 Rohde LF-01.108.01 Grab rail Silver (L x W x H) 120 x 27 x 60 mm 2 pc(s)
User & Safety Instructions
User & Safety Instructions 2343736 Rohde LF-01.108.01 Grab rail Silver (L x W x H) 120 x 27 x 60 mm 2 pc(s)
Description
Material and surface:
Profile aluminum AlMgSi 0.5; slide-ground, matt and natural colors or black anodized.
Note:
Any other handle lengths and colors on request.
Load capacity:
min 500 N.
This text is machine translated.
Profile aluminum AlMgSi 0.5; slide-ground, matt and natural colors or black anodized.
Note:
Any other handle lengths and colors on request.
Load capacity:
min 500 N.
This text is machine translated.
Scope of delivery
- Material and surface:
- Profile aluminum AlMgSi 0.5
- slide-ground, matt and
- natural or black
- anodized.
