Rohde LG-02.045.01 Grab rail Silver (L x W x H) 60 x 9.7 x 15.5 mm 7 pc(s)
Product type
Grab rail
Material
Aluminium
Dim
(L x W x H) 60 x 9.7 x 15.5 mm
Width
9.7 mm
Height
15.5 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Rohde bar handles, made of profile aluminum
- Content: 7 pcs
Technical specifications
- Surface treatment: Anodized
- Material (material): AlMgSi 0.5
- Manufacturer color: silver
- Mounting method: Internal thread
- Series name: LG-02
- Handle type (series): LG
- Hole diameter: M4
- Dim
(L x W x H) 60 x 9.7 x 15.5 mm
- Product type
Grab rail
- Material
Aluminium
- Width
9.7 mm
- Height
15.5 mm
- Length
60 mm
- Hole spacing
45 mm
- Factory colour
Silver
- Content
7 pc(s)
- Hole Ø
4 mm
- Max. load capacity
200 N
- Type
LG-02.045.01
Documents & Downloads
Datasheet
Datasheet 2343748 Rohde LG-02.045.01 Grab rail Silver (L x W x H) 60 x 9.7 x 15.5 mm 7 pc(s)
User & Safety Instructions
User & Safety Instructions 2343748 Rohde LG-02.045.01 Grab rail Silver (L x W x H) 60 x 9.7 x 15.5 mm 7 pc(s)
Description
Material and surface:
Profile aluminum AIMgSi 0.5;
slide-ground, matt and
natural or black
This text is machine translated.
Profile aluminum AIMgSi 0.5;
slide-ground, matt and
natural or black
