Name: Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function
Brand: Roline
SKU: 3798272

Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function-0

Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function-1

Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function-2

Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function-3

Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function-4

1/5

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

ROLINE 21.13.1135 Network Media Converter 1000 Mbit/s Multi-Mode Black

1000 Mbit/s 500 m
Multi-mode SFP
Black

Technical specifications

Maximum data transfer rate of 1000 Mbit/s.
Optical cable type: SFP+

Product type: Network switch

LAN transfer rate: 1000 MBit/s

Transfer rate: 10 / 100 / 1000 MBit/s

Weight: 474.8 g

Width: 106 mm

Height: 40 mm

Depth: 140 mm

Type: 21.13.1135

Factory colour: Black

Cable design: Round

Version: Cable

Length: 140 mm

Interfaces: SFP
RJ45

Cable use: C13/C14 appliances

Link: LAN 10/100/1000 MBit/s

UKCA: yes

Operating temperature (T-T): -20 - 70 °C

Power over Ethernet plus (PoE+) ports quantity: 1

Internal: no

Maximum transfer distance: 500 m

Documents & Downloads

Datasheet

Datasheet 3798272 Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function

User & Safety Instructions

User & Safety Instructions 3798272 Roline industrial converter Gigabit Ethernet – Dual speed 100/1000 fiber, with PoE function

Description

Network converter for use in industrial environments Industrial media converter with 1x 10/100/1000 Mbps RJ45 port and 1x 100/1000 Mbps SFP slot (Dual speed) for recording standard mini-GBICs including Gigabit SFP module with 1x SM LC 10km, PoE according to IEEE802.3af/at/t standard, management via Web, SNMP, Power Saving EEE, DIN rail mounting, Optimised latency behavior, extended temperature range, without fan in the metal housing Full Wire speed conversion of the Gigabit Ethernet signal. AUTO MDI/MDI X Link Fault Pass Through function (error detection at the far end). Transparent conversion of 802.1Q VLAN packets. Low power consumption. DIN Rail mount Operating voltage +7 to +30VDC. Operating temperature range -20°C - +70°C. Current connection via screw terminal block or DC hollow plug. Power supply +12 to +57 VDC, . Power supply not included in delivery. We recommend the DIN rail power supply NDR-75-24 (21.13.1311).

This text is machine translated.
