RST 11480516R Cable gland M16 x 1.5 Polyamide 6 50 pc(s)
Product type
Cable gland
External thread
M16 x 1.5
Material
Polyamide 6
Clamp Ø
3 mm
Terminal Ø (max.)
7 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
RST 11480516R - Euro Top PA / M Long thread RAL 7035 - Cable gland - 50 pcs
Our service for you
Technical specifications
- Material Seal insert: Chloroprene
- operating temperature min: -40 °C
- operating temperature max: +100 °C
- Note: Cable gland, tested and approved among others according to EN 62444 and UL514B
- Product type
Cable gland
- External thread
M16 x 1.5
- Material
Polyamide 6
- Clamp Ø
3 mm
- Terminal Ø (max.)
7 mm
- Thread length
15 mm
- Length
30 mm
IP66
IP68
- Spanner size
22 mm
22 mm
- Content
50 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
11480516R
- Type
Euro Top PA / M Langgewinde RAL 7035
- RAL no.
7035
Documents & Downloads
Datasheet
Datasheet 2256576 RST 11480516R Cable gland M16 x 1.5 Polyamide 6 50 pc(s)
User & Safety Instructions
User & Safety Instructions 2256576 RST 11480516R Cable gland M16 x 1.5 Polyamide 6 50 pc(s)
