Schneider Electric C10V35E040 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 105 x 161 x 86 mm S

This compact NSX100HB1 is a complete fixed-mount 3P 3d circuit breaker designed to optimize space requirements and breaking capacity. It is an optimum choice for all standard and special applications. The breaking capacity (ICU) is 85 kA eff. At 500 VAC 50/60 Hz and 75 kA eff. At 690 VAC 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product has an electronic trigger MicroLogic 5.2 E with a nominal power of 40 A. The trigger device MicroLogic 5.2 E offers an adjustable long-term, short-time and instantaneous protection. MicroLogic 5.2 E has an integrated display for fine-tuning and displaying the energy meter. This 3-pole version (105 mm x 161 mm x 86 mm) comes with a variety of optional functions and accessories. It complies with international standards (IEC 60947), CCC, EAC and Marine specifications. Compact NSX100HB1 is part of Schneider Electric's EcoStruxure power architecture.

This text is machine translated.
