Name: Schneider Electric TM171OFM22R TM171OFM22R Expansion 24 V DC
Brand: Schneider Electric
SKU: 2912746
Availability: BackOrder

Datasheet (PDF)

Dispatches on Thu 22 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 229.99 / piece)

€ 229.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

SIMATIC S7-200 is easy: programming software with Windows user interface
instructions for quick access to PLC technology
easy installation onto a top hat profile rail
SIMATIC S7-200 is compact: e.g. CPU 222: (W x H x D) 90 x 80 x 62 mm
own S7-200 net with PPI protocol
freely programmable interface.

Technical specifications

Product type: Expansion

No. of analogue inputs: 5

No. of analogue outputs: 5

No. of digital inputs (max.): 6

No. of inputs (max.): 11

No. of outputs (max.): 11

No. of relay outputs (max.): 6

No. of transistor outputs (max.): 1

Operating voltage: 24 V DC

Type: TM171OFM22R

Manufacturer part #: TM171OFM22R
