Self Electronics SLT100-48VFG-UN LED driver Constant voltage 100 W 0 A - 2080 mA 48 V DC not dimmable, Suitable for flam
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SLT100-48VFG-UN
- Constant voltage
- 48 V DC
- 0 A - 2080 mA
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Dim
(L x W x H) 298 x 29.8 x 16.5 mm
- Factory colour
Grey
Blue
- Output voltage (max.)
48 V DC
- Test mark
MM · SELV · ENEC · UL
- Max. output current
2080 mA
- Output current (max.) - rounded
2.08 A
- Operating voltage
115 V AC
230 V AC
- Protection class
II
- LED driver features
not dimmable
Suitable for flammable surfaces
Approved for use on furniture
Surge protection
Overvoltage
IP20
- Connection
Screw terminal
- Max. power
100 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
0 A
- Input voltage (max.)
264 V AC
- Min. input voltage
108 V AC
- Weight
216 g
- Power range
100 W (max)
- Type
Pulsed
- Width
29.8 mm
- Height
16.5 mm
- Length
298 mm
- Max. temperature
+45 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2176590 Self Electronics SLT100-48VFG-UN LED driver Constant voltage 100 W 0 A - 2080 mA 48 V DC not dimmable, Suitable for flam
User & Safety Instructions
User & Safety Instructions 2176590 Self Electronics SLT100-48VFG-UN LED driver Constant voltage 100 W 0 A - 2080 mA 48 V DC not dimmable, Suitable for flam
Description
Features
- Independant operating device
- Protection class II, SELV output
- Constant voltage
- IP20
- Protected against overload, short circuit, overvoltage and temperature protection
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
