Siemens 5SJ43037HG41 5SJ4303-7HG41 Circuit breaker 3 A 400 V
EAN:
Part number:
Item no:
Product type
Circuit breaker
Number of pins
3
Release characteristics
C
Nominal current - rounded value
3 A
RoHS-compliant
Yes
Datasheet (PDF)
Sales and shipping:
Number
Total (€ 239.50 / piece)
€
Technical specifications
- IP20, with the connected conductors, IP40 in the grip area
- Product type
Circuit breaker
- Number of pins
3
- Release characteristics
C
- RoHS-compliant
Yes
- Nominal current - rounded value
3 A
- Nominal current
3 A
- Factory colour
Grey
- Dim
(W x H x D) 54 x 90 x 76 mm
- Content
1 pc(s)
- Switch-off capacity
14 kA
- Operating voltage
240 V
- Nominal voltage
400 V
- Compatible with (details)
SENTRON
- Width
54 mm
- Height
90 mm
- Depth
76 mm
AC/DC
70 mm
3 A
400 V
50-60 MHz
C
440 V
3
3
3
IP20
3
FALSE
TRUE
3
10 kA
10 kA
15 kA
15 kA
Documents & Downloads
Datasheet
Datasheet 1752028 Siemens 5SJ43037HG41 5SJ4303-7HG41 Circuit breaker 3 A 400 V
User & Safety Instructions
User & Safety Instructions 1752028 Siemens 5SJ43037HG41 5SJ4303-7HG41 Circuit breaker 3 A 400 V
Description
SIMATIC DP, Electronics module for ET 200S, 2 AO U High Speed, 15 mm width, +/-10 V, +/-5 V, 1.. 5V 16 bit, Cycle time: 0.1ms with SF LED (group fault)
