Name: Signal Construct SMZD08622 LED indicator light White 12 V DC 250 mcd
Brand: Signal Construct
SKU: 150491
Availability: InStock

Green electrical connector with metal threading and two gold-coloured contacts. Used for connecting cables.

Image similar

Product type

LED indicator light

Operating voltage

12 V DC

Operating current

17 mA

Recess diameter

8 mm

Light intensity I(V)

250 mcd

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

69 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 4.79 / piece)

€ 7.99

-40 %

€ 4.79

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Signal Construct SMZD08622 LED indicator light White 12 V DC 250 mcd

Our service for you

Technical specifications

Product type: LED indicator light

Type: SMZD08622

Factory colour: White

Operating voltage: 12 V DC

Operating current: 17 mA

Recess diameter: 8 mm

Head Ø: 9.5 mm

Case colour: White

Material: Brass

Material properties: chrome plated

Mounting type: Screw

Light intensity I(V): 250 mcd

LED features: Built-in reflector

Connection: Type C CEE 7/16 plug 2.8 mm

Length: 40 mm

: min 60000 h

Min. temperature: -35 °C

Max. temperature: 75 °C

RoHS-compliant: Yes

Type (LEDs): White

Type: Internal reflector

Content: 1 pc(s)

Temperature range: -35 - +75 °C

Operating voltage: 12 V DC

Documents & Downloads

Datasheet

Datasheet 150491 Signal Construct SMZD08622 LED indicator light White 12 V DC 250 mcd

Description

LED indicator for direct operation on the given nominal voltage. The series resistor required with standard LEDs is already inbuilt into the housing making standard wiring superfluous. And the chrome-plated brass housing, the wide working temperature range and long life make it incredibly versatile. Connection is by means of fast-on connections or soldering.
