Sol Expert S18JST Micro servo 0.15 s
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.92
3
5% = € 0.55
€ 10.37
5
7% = € 0.76
€ 10.16
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.92 / piece)
€ 10.92
plus VAT.
Highlights & Details
Micro servo S18JST, 1.8 grams
- Model Car Tuning
Technical specifications
- Speed: 0.15 sec / 60 degrees
- Size
Universal
- Servo speed (60 degrees)
0.15 s
- Actuating power (at 6 V)
0.25 kg/cm
- Voltage (min.)
3.5 V
- Voltage (max.)
6 V
- Length
16 mm
- Width
13.5 mm
- Height
6 mm
- Dim
(L x W x H) 16 x 13.5 x 6 mm
- Weight
1.8 g
- Product type
Micro servo
Documents & Downloads
Datasheet
Datasheet 2471404 Sol Expert S18JST Micro servo 0.15 s
User & Safety Instructions
User & Safety Instructions 2471404 Sol Expert S18JST Micro servo 0.15 s
Information
Information 2471404 Sol Expert S18JST Micro servo 0.15 s
Description
One of the smallest servos in the world
This servo is characterized by the smallest dimensions (13.5 x 16 x 6 mm) and an extremely low weight (1.8 g). Nevertheless, it offers an actuating power of 0.25 kg / cm² at 6 V and is protected by its classical casing in contrast to many other micro servos. It is therefore perfectly suitable for small models, special functions and models, which due to their shape offer only little space for the installation of a servo. Apart from the classic steering, there are no limits to the fantasy; lifting and lowering movements, door openers, signal poles, couplings etc., almost everything is now possible in a simple way. The servo has a JST plug. With our JST-JR adapter, the servos can also be plugged directly into JR sockets.
