Theben TR 622 top2 24V DIN rail mount timer 12 V
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Automatic summer/winter time changeover: Yes
- Width in the division units: 2
- Nominal Switching power at 250 V AC: 16 A
- Frequency of the power supply: 50 Hz
- Type of voltage supply: AC/DC
- Contact Type: changer
- Protection class: IP20
- Installation type: DIN rail
- Product type
DIN rail mount timer
- Operating voltage
12 V
- Channels
2-channel
- Type
TR 622 top2 24V
- Manufacturer part #
6224100
- Height
90 mm
- Length
60 mm
DIN rail
35
90 mm
60 mm
Change-over contact (NO/NC)
2
AC/DC
IP20
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2158263 Theben TR 622 top2 24V DIN rail mount timer 12 V
User & Safety Instructions
User & Safety Instructions 2158263 Theben TR 622 top2 24V DIN rail mount timer 12 V
User & Safety Instructions 2158263 Theben TR 622 top2 24V DIN rail mount timer 12 V
Description
Digital timer clock for DIN-rail, external inputs, text-oriented operator guidance on the display, width 2 TE, power reserve and programd summer/winter time changeover, day and week program, DuoFix plug-in terminals, OBELISK interface for PC-programming, memory card included, 2 channels
