TP-LINK OMADA ER8411 V1 - Router 10GbE - - -AN

  • Integrated with Omada SDN - zero-touch provisioning (ZTP), centralized cloud management and intelligent monitoring
  • Centralized management – cloud access and Omada APP for maximum convenience and ease of management
  • Two 10GE SFP+ ports - 1x WAN and 1x WAN/LAN 10GE SFP+ ports provide high-bandwidth aggregation connectivity
  • Up to 10 WAN ports - fiber optic and load-balanced RJ45 WAN ports increase the utilization rate of multi-wire broadband connections
  • Highly secure VPN - SSL/IPSec/PPTP/L2TP VPN according to the company standard and OpenVPN/L2TP over IPSec VPN are Ideal for use in multiple branches and for WFH
  • Extensive security features - powerful firewall, Dos Defense, IP/MAC/URL filtering and IP MAC binding as well as ALG activation with one click provide first-class security

Technical specifications

  • Rack mountable
Product type

Router

Type

Router

Function

Router

LAN data transfer rate

10 GBit/s

Interfaces

SFP+

Features

Mesh support

10/100/1000 Mbps ports

8 x

Manufacturer-specific

Width

440 mm

Height

44 mm

Depth

220 mm

Weight

3.79

Factory colour

Black

Memory techology

DDR4

Power supply (details)

100 - 240 V

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 3732949 TP-LINK Router Router

User & Safety Instructions

User & Safety Instructions 3732949 TP-LINK Router Router

Description

Manage your entire corporate network with the right amount of computing power. Dual redundant power supplies provide carrier-class reliability for enterprise networks. Maximized 10G broadband with the Omada Enterprise Gateway Build your lightning-fast network with the Omada ER8411 - an enterprise VPN router with 10G ports. It exceeds the need for fast, reliable and secure corporate networks and is Ideal for large installations such as offices, schools and hotels. With up to 10x WAN SFP+, SFP and RJ45 ports, the router can meet different Internet access requirements. Multi-WAN load balancing distributes the data streams according to the bandwidth share of each WAN port, in order to increase the utilization of multi-line broadband. Connect a 4G/3G modem to one of the USB 3.0 ports for LTE WAN backup. The ER8411 supports pass-through traffic and multiple VPN protocols, including SSL, IPSec, PPTP and L2TP in client/server mode. One-click automatic IPSec VPN configuration simplifies VPN configuration and simplifies network management and deployment. The router also has built-in VPN engine hardware that supports and manages hundreds of IPSec, PPTP, L2TP, SSL-VPN and OpenVPN tunnels. The Omada Software Defined Networking (SDN) platform integrates network devices such as access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network - all controlled from a single interface.

This text is machine translated.

Features

  • TP-LINK OMADA ER8411 V1 - Router - can be mounted on rack
  • Device Type : Routers
  • Housing Type : Rack mountable
  • Digital Signaling Protocol : H.323, SIP
  • Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
  • Performance : NAT upload throughput (static IP): 9445.82 Mbps
  • NAT download throughput (static IP): 9449.26 Mbps
  • NAT upload throughput (DHCP): 9426.83 Mbps
  • NAT download throughput (DHCP): 9426.20 Mbps
  • NAT upload throughput (PPPoE): 9413.96 Mbps
  • NAT download throughput (PPPoE): 9102.01 Mbps
  • NAT upload throughput (L2TP): 4230.62 Mbps
  • NAT download throughput (L2TP): 4169.53 Mbps
  • NAT upload throughput (PPTP): 3933.86 Mbps
  • NAT download throughput (PPTP): 3821.97 Mbps
  • Upload forwarding rate (packet size 66 bytes): 1080 Mbps
  • Download forwarding rate (packet size 66 bytes): 1030 Mbps
  • VPN-throughput (256-bit AES+SHA1 IPSec): 2140.45 Mbps
  • VPN throughput (256 bit AES+SHA2 IPSec) 2080.20 Mbps
  • OpenVPN throughput: 1665.64 Mbps
  • Unencrypted VPN throughput (L2TP): 5013.50 Mbps
  • Encrypted VPN (L2TP) throughput: 2274.74 Mbps
  • VPN throughput (SSL): 1511.10 Mbps
  • Capacity : Simultaneous sessions: 2300000
  • New sessions per second: 20000
  • OpenVPN tunnels: 500
  • IPSec VPN tunnel:300
  • L2TP VPN Tunnel: 300
  • PPTP VPN-Tunnel 300
  • OpenVPN tunnels: 110
  • NETWORK/TRANSPORT PROTOCOL : TCP/IP, PPTP, UDP/IP, L2TP, NTP, ICMP/IP, IPSec, PPPoE, ARP, FTP, DHCP, DNS, IPv6
  • Routing Protocol : IGMPv2, static IP routing, IGMPv3
  • Remote management protocol : SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, COMP
  • VoIP protocols : H.323, SIP
  • Features : Network monitoring, NAT support, VLAN support, Syslog support, ALG support, VPN pass-through, URL filtering, Ethernet pass-through port, ACL support, DPD, IPSec NAT-T, virtual server support, DHCP server, reset key, port control, SPIF, IP MAC integration, DHCP client, static routing, VPN server, GARP, DoS, Ping of Death, IGMP Proxy, Bandwidth Control per Port, 2 fans, ARP inspection, 4 kV surge protector, SDN, web filtering, VPN client, policy-based routing, hotspot access point capability, PFS, ZTP, L2TP over IPSec, DMZ support, Mac clone, fixed-time restart, OpenVPN client, PPTP VPN client, OpenVPN server, IPTV support, Load balancing network mode, device detection, address reservation, session rate limiting, USB backup
  • Product certifications : IEEE 802.1Q, UPnP
  • Power supply : AC 100-240 V (50/60 Hz)
  • Dimensions (width x depth x height): 44 cm x 22 cm x 4.4 cm
  • System requirements : UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/8.1/10, Microsoft Windows 11
