TracoPower TDR 3-2411WI DC/DC converter (print) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 33.61 / piece)
€ 33.61
plus VAT.
Only 6 Piece(s) available
Highlights & Details
DC/DC converter TDR 3WI series, 3 Watt, DIL-casing
- 3-year manufacturer's guarantee
Technical specifications
- Control deviations: input change ±0.2 %, load change ±1 %
- Ripple: 30 mVpk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (print)
- Type
TDR 3-2411WI
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
600 mA
- Output current (max.) - rounded
600 mA
- Efficiency (max.)
80 %
3 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 14
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 18.9 x 12.8 x 8.7 mm
- Height
8.7 mm
- Length
18.9 mm
- Width
12.8 mm
- Content
1 pc(s)
3 W
- Operating temperature
(above 70ºC power reduction) -40 to +85 °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 157231 TracoPower TDR 3-2411WI DC/DC converter (print) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 157231 TracoPower TDR 3-2411WI DC/DC converter (print) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 157231 TracoPower TDR 3-2411WI DC/DC converter (print) 24 V DC 5 V DC 600 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact features in the DIL 14 casing, ultra-wide 4:1 input range, no base load required. Regulated outputs, external on/off (standby 2.5 mA). Safety standards: UL/cUL 60950-1, EN 60950-1 and IEC 60950-1.
