TracoPower THM 15-2423 DC/DC converter (print) 500 mA 15 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
11 Piece(s)
Sales and shipping:
Number
Total (€ 63.86 / piece)
€
Technical specifications
- Type
THM 15
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Efficiency (max.)
90 %
15 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 40.60 x 25.40 x 10.20 mm
- Height
10.20 mm
- Length
40.60 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
24 g
- Product type
DC/DC converter (print)
