TracoPower THN 30-4813WI DC/DC converter (print) 48 V DC 15 V DC 2.5 A 30 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
Part number:
Item no:
Number
Minimum order quantity: 10
Total (€ 93.99 / piece)
€ 93.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 30-4813WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
2.5 A
- Output current (max.) - rounded
2.5 A
- Efficiency (max.)
91 %
30 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 25.4 x 25.4 x 20.32 mm
- Height
20.32 mm
- Length
25.4 mm
- Width
25.4 mm
- Output voltage (max.)
15 V DC
- Output voltage (min.)
15 V DC
- Weight
16.5 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3371104 TracoPower THN 30-4813WI DC/DC converter (print) 48 V DC 15 V DC 2.5 A 30 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371104 TracoPower THN 30-4813WI DC/DC converter (print) 48 V DC 15 V DC 2.5 A 30 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371104 TracoPower THN 30-4813WI DC/DC converter (print) 48 V DC 15 V DC 2.5 A 30 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371104 TracoPower THN 30-4813WI DC/DC converter (print) 48 V DC 15 V DC 2.5 A 30 W No. of outputs: 1 x Content 1 pc(s)
Description
Ultra-compact dimensions: 25.4 mm x 25.4 mm x 10.2 mm, 4:1 input range, input/output insulation 1500 V/DC, external on/off, input filter according to EN 55022, class A.
This text is machine translated.
This text is machine translated.
