Name: TracoPower THP 3-4822 DC/DC converter (print) 48 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Brand: TracoPower
SKU: 3370009
Availability: BackOrder

TracoPower THP 3-4822 DC/DC converter (print) 48 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s)-0

Datasheet (PDF)

EAN:

Part number:

Item no:

Available soon

8 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 10

Total (€ 75.99 / piece)

€ 759.90

incl. VAT

Only 8 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

DC/DC converter THP 3 series, 3 Watt, 4:1 input, reinforced insulation

3-year manufacturer's guarantee

Technical specifications

Control deviations: input change ±0.5 %, load change ±1 %
Ripple: 150 mVpk-pk (20 MHz bandwidth)

Product type: DC/DC converter (print)

Type: THP 3-4822

Nominal voltage: 48 V DC

Min. input voltage: 18 V DC

Input voltage (max.): 80 V DC

No. of outputs: 2 x

Output voltages: 12 V DC
-12 V DC

Max. output current: 125 mA

Output current (max.) - rounded: 125 mA

Efficiency (max.): 83 %

: 3 W

Insulation voltage: 4000 V DC

Enclosure: DIL 24

Connection: Solder pins

Operating temperature (min.): -40 °C

Operating temperature (max.): 85 °C

Dim: (L x W x H) 32 x 20 x 10 mm

Height: 10 mm

Length: 32 mm

Width: 20 mm

Content: 1 pc(s)

: 3 W

Type: THP Series

Operating temperature: (above 75ºC power reduction) -40 to +85 °C

Insulation voltage: (60 s/50 Hz) efficiency. 4000 V AC

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

Datasheet

Datasheet 3370009 TracoPower THP 3-4822 DC/DC converter (print) 48 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3370009 TracoPower THP 3-4822 DC/DC converter (print) 48 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s)

Warranty Terms

Warranty Terms 3370009 TracoPower THP 3-4822 DC/DC converter (print) 48 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s)

Description

Ultra-wide 4:1 input range, input/output insulation 4000 V/AC eff., short circuit protection. Reinforced insulation for 300 V/AC operating voltage, safety standards for medical and industrial applications. Input filter according to EN 55022, Class A. Safety standards/approvals cUL / UL 60950-1, IEC/EN 60950-1, EN 50124-1&2, IEC/EN 60601-1, CSA C22.2.
