TracoPower TMDC 06-2415 DC/DC converter 250 mA 6 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
9 Piece(s)
Show alternatives
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 43.69 / piece)
€
Only 9 Piece(s) available
Technical specifications
- Product type
DC/DC converter
- Type
TMDC 06-2415
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Max. output current
250 mA
- Output current (max.) - rounded
250 mA
- Efficiency (max.)
85 %
6 W
- Insulation voltage
3000 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 53 x 34 x 26.50 mm
- Height
26.50 mm
- Length
53 mm
- Width
34 mm
- RoHS-compliant
Yes
- Output voltage (max.)
24.0 V DC
- Output voltage (min.)
24.0 V DC
- Weight
49 g
- Content
1 pc(s)
