TracoPower TME 0305S DC/DC converter (print) 3.3 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
Part number:
Item no:
Number
Minimum order quantity: 10
Total (€ 10.99 / piece)
€ 10.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TME 0305S
- Nominal voltage
3.3 V DC
- Min. input voltage
2.97 V DC
- Input voltage (max.)
3.63 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
77 %
1 W
- Insulation voltage
1000 V DC
- Enclosure
SIL 4
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.5 x 13.4 x 7.1 mm
- Height
7.1 mm
- Length
19.5 mm
- Width
13.4 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
2.6 g
- Content
1 pc(s)
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3371122 TracoPower TME 0305S DC/DC converter (print) 3.3 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371122 TracoPower TME 0305S DC/DC converter (print) 3.3 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371122 TracoPower TME 0305S DC/DC converter (print) 3.3 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371122 TracoPower TME 0305S DC/DC converter (print) 3.3 V DC 5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
SIL-4 housing, unregulated output, input/output insulation 1000 V/DC, industry standard footprint.
This text is machine translated.
This text is machine translated.
